TOYOTA RAV4 2005 - 2008 SERVICE & REPAIR INFORMATION MANUAL
  • TOYOTA RAV4 2005 - 2008 SERVICE & REPAIR INFORMATION MANUAL
  • TOYOTA RAV4 2005 - 2008 SERVICE & REPAIR INFORMATION MANUAL
  • TOYOTA RAV4 2005 - 2008 SERVICE & REPAIR INFORMATION MANUAL
  • TOYOTA RAV4 2005 - 2008 SERVICE & REPAIR INFORMATION MANUAL

TOYOTA RAV4 2005 - 2008 SERVICE & REPAIR INFORMATION MANUAL

$60.00
Brand: Toyota
Product Code: Toyota
Availability: In Stock
Qty:

11.2005 - 11.2008 / All Regions / 1 CD / Windows 10, Windows 8, Windows 7, Windows Vista, Windows XP / 32 & 64 bit

Toyota RAV4 Service information library 11.2005 - 11.2008

Language: English

ACA30, ACA33, ACA38, ALA30 series
Left Hand Drive & Right Hand Drive
Engines:
2AD-FHV - 2.2L 4cylinder D-CAT 16 Valve DOHC turbo diesel
2AD-FTV - 2.2L 4cylinder D-4D 16 Valve DOHC turbo diesel
1AZ-FE - 2.0L 4cylinder 16 Valve DOHC
2AZ-FE - 2.4L 4cylinder 16 Valve DOHC

Repair Manual
New car features
Electrical wiring diagram
Body Repair
Service data sheet

All car units service & repair, troubleshooting, installation, removal, components, diagrams, inspection, replacement, wiring diagrams, trouble codes, other information

DESCRIPTION:

REPAIR MANUAL
ENGINE
ENGINE CONTROL SYSTEM
2AD-FHV - ECD system, Mass air flow meter, Camshaft position sensor, Crankshaft position sensor, Engine coolant temperature sensor, Intake air temperature sensor, Diesel throttle body, IG1 relay, IG2 relay, ECM, Manifold absolute pressure sensor, Accelerator pedal rod
2AD-FTV - ECD system, Mass air flow meter, Camshaft position sensor, Crankshaft position sensor, Engine coolant temperature sensor, Intake air temperature sensor, Diesel throttle body, Integration relay, IG1 relay, IG2 relay, ECM, Manifold absolute pressure sensor, Accelerator pedal rod
1AZ-FE - SFI system, Mass air flow meter, Camshaft timing oil control valve assembly, Camshaft position sensor, Crankshaft position sensor, Engine coolant temperature sensor, Throttle body, Knock sensor, Integration relay, IG1 relay, IG2 relay, Circuit opening relay, ECM, Accelerator pedal rod
2AZ-FE - SFI system, Mass air flow meter, Camshaft timing oil control valve assembly, Camshaft position sensor, Crankshaft position sensor, Engine coolant temperature sensor, Throttle body, Knock sensor, Integration relay, IG1 relay, IG2 relay, Circuit opening relay, ECM, Accelerator pedal rod

ENGINE MECHANICAL
2AD-FHV - Engine, Drive belt, Engine assembly, Engine unit
2AD-FTV - Engine, Drive belt, Engine assembly, Engine unit
1AZ-FE - Engine, Drive belt, Valve clearance, Timing chain, Cylinder head, Engine assembly, Engine unit
2AZ-FE - Engine, Drive belt, Valve clearance, Timing chain, Cylinder head, Engine assembly, Engine unit

FUEL
2AD-FHV - Fuel system, Fuel injector, Fuel supply pump, Common rail, Fuel filter, Injector driver, Fuel tank
2AD-FTV - Fuel system, Fuel injector, Fuel supply pump, Common rail, Fuel filter, Fuel cooler, Injector driver, Fuel tank
1AZ-FE - Fuel system, Fuel injector, Fuel pressure regulator, Fuel pressure pulsation damper, Fuel pump, Fuel tank
2AZ-FE - Fuel system, Fuel injector, Fuel pressure regulator, Fuel pressure pulsation damper, Fuel pump, Fuel tank

EMISSION CONTROL
2AD-FHV - Emission control system, EGR valve, EGR cooler, Exhaust fuel addition injector, Exhaust manifold converter, Vacuum switching valve, Air fuel ratio sensor, Differential pressure sensor, Exhaust gas temperature sensor
2AD-FTV - Emission control system, EGR valve, EGR coller, Fuel tank cap
1AZ-FE - Emission control system, Canister, Vacuum switching valve, Ventilation valve, Air fuel ratio sensor, Heated oxygen sensor, Fuel tank cap
2AZ-FE - Emission control system, Canister, Vacuum switching valve, Ventilation valve, Air fuel ratio sensor, Heated oxygen sensor, Fuel tank cap

INTAKE / EXHAUST
2AD-FHV - Intake air control system, Vacuum regulating valve, Turbocharger, Intercooler, Exhaust pipe
2AD-FTV - Intake air control system, Vacuum regulating valve, Turbocharger, Intercooler, Exhaust pipe
1AZ-FE - Exhaust pipe
2AZ-FE - Exhaust pipe

COOLING
2AD-FHV - Cooling system, Cooling fan system, Coolant, Water pump, Thermostat, Fan motor, Fan relay, Radiator
2AD-FTV - Cooling system, Cooling fan system, Coolant, Water pump, Thermostat, Fan motor, Fan relay, Radiator
1AZ-FE - Cooling system, Cooling fan system, Coolant, Water pump, Thermostat, Fan motor, Fan relay, Radiator
2AZ-FE - Cooling system, Cooling fan system, Coolant, Water pump, Thermostat, Fan motor, Fan relay, Radiator

LUBRICATION
2AD-FHV - Lubrication system, Oil filter, Oil pump, Engine Oil cooler
2AD-FTV - Lubrication system, Oil filter, Oil pump, Engine Oil cooler
1AZ-FE - Lubrication system, Oil filter, Oil pump, Engine oil cooler
2AZ-FE - Lubrication system, Oil filter, Oil pump, Engine oil cooler

IGNITION
1AZ-FE - Ignition system, Ignition coil
2AZ-FE - Ignition system, Ignition coil

STARTING
2AD-FHV - Starting system, Pre-heating system, Entry and start system, Glow plug, Starter, Starter relay, Glow relay, Engine switch, Ignition switch
2AD-FTV - Starting system, Pre-heating system, Entry and start system, Glow plug, Starter, Starter relay, Glow relay, Engine switch, Ignition switch
1AZ-FE - Starting system, Entry and start system, Starter, Starter relay, Engine switch, Ignition switch
2AZ-FE - Starting system, Starter, Starter relay, Ignition switch

CHARGING
2AD-FHV - Charging system, Generator, Battery current sensor
2AD-FTV - Charging system, Generator, Battery current sensor
1AZ-FE - Charging system, Generator, Battery current sensor
2AZ-FE - Charging system, Generator, Battery current sensor

TRANSMISSION
U140F Automatic Transaxle - Automatic transaxle system, Fluid, Speed sensor, Park / Neutral position switch, Transmission wire, Valve body assembly, Shift lock system, Oil cooler, Transmission control cable assembly, Floor shift assembly, Differential oil seal, Automatic transaxle assembly, Torque converter and drive plate, Transaxle unit, Oil pump, Second brake piston, Forward clutch, Direct clutch, Underdrive planetary gear, Underdrive clutch, Valve body, Differential case
U241E Automatic Transaxle - Automatic transaxle system, Fluid, Speed sensor, Park / Neutral position switch, Transmission wire, Valve body assembly, Shift lock system, Oil cooler, Transmission control cable assembly, Floor shift assembly, Differential oil seal, Automatic transaxle assembly, Torque converter and drive plate, Transaxle unit, Oil pump, Second brake piston, Forward clutch, Direct clutch, Underdrive planetary gear, Underdrive clutch, Valve body, Differential case
Clutch - Clutch system, Clutch pedal, Master cylinder, Release cylinder, Clutch accumulator, Clutch unit, Clutch start switch, Clutch start cancel switch
E352 Manual Transaxle - Manual transaxle system, Oil, Differential oil seal, Floor shift lever assembly, Transmission control cable, Back up light, Transaxle assembly, Transaxle unit, Input shaft, Output shaft, Shift and select lever shaft, Differential case
E352F / E359F Manual Transaxle - Manual transaxle system, Oil, Differential oil seal, Floor shift lever assembly, Transmission control cable, Back up light, Transaxle assembly, Transaxle unit, Input shaft, Output shaft, Shift and select lever shaft, Differential case
EA64F Manual Transaxle - Manual transaxle system, Oil, Differential oil seal, Floor shift lever assembly, Transmission control cable, Back up light, Transaxle assembly, Transaxle unit, Input shaft, Output shaft, Shift and select lever shaft, Differential case

DRIVE LINE
GF1A Transfer - Transfer system, Active torque control 4WD system, Oil, Case oil seal, Transfer assembly, 4WD control ECU
Propeller Shaft - Propeller shaft system, Propeller shaft assembly
Drive Shaft - Drive shaft system, Front drive shaft assembly, Rear drive shaft assembly
Differential - Differential system, Differential oil, Rear differential side gear shaft oil seal, Diaphragm oil seal, Rear differential carrier assembly

SUSPENSION & AXLE
Axle - Axle system, Front axle hub bolt, Front axle hub, Rear axle hub bolt, Rear axle hub and bearing
Suspension - Suspension system, Front wheel alignment, Rear wheel alignment, Front shock absorber, Front suspension lower arm, Front lower ball joint, Front stabilizer bar, Rear coil spring, Rear shock absorber, Rear upper control arm, Rear suspension arm, Rear trailing arm, Rear stabilizer bar
Tire and Wheel - Tire and wheel system, Tire pressure warning system

BRAKE
Brake Control - Anti lock brake system, Vehicle stability control, Brake actuator, Front speed sensor, Skid control system, Rear speed sensor, Yaw rate and deceleration sensor, Steering angle sensor, Downhill assist control switch
Brake - Brake system, Fluid, Brake pedal, Master cylinder, Brake booster, Vacuum pump, Front brake, Front brake flexible hose, Rear brake, Rear brake flexible hose
Parking Brake - Parking brake system, Parking brake lever, Parking brake cable, Parking brake assembly

STEERING
Steering Column - Steering system, Steering lock system, Steering column assembly
Power Steering - Electronic power steering system, Steering gear, Power steering ECU

HEATER & AIR CONDITIONING
Air Conditioning - Air conditioning system, Refrigerant, Refrigerant line, Air conditioning unit, Blower unit, Blower resistor and motor, Control servo motor, PTC heater assembly, Compressor and pulley, Condenser, Evaporator temperature sensor, Temperature sensor, Solar sensor, Heater relay, Air conditioning control assembly
Heater - Heater switch, Heater assembly
RESTRAINTS
Supplemental Restraint System - Airbag system, Steering pad, Spiral cable, Driver side knee airbag assembly, Front passenger airbag assembly, Curtain shield airbag, Front seat side airbag, Center airbag sensor assembly, Front airbag sensor, Seat position sensor, Airbag cut off switch
Seat Belt - Seat belt warning system, Front seat inner belt assembly, Front seat outer belt assembly, Rear seat inner belt assembly, Rear seat outer belt assembly, Rear center seat outer belt assembly, Child restraint seat tether anchor

SECURITIES
Theft Deterrent - Theft deterrent system, Engine hood courtesy switch
Engine Immobiliser - Engine immobiliser system, Unlock warning switch

CRUISE CONTROL SYSTEM
Cruise Control - Cruise control system, Cruise control main switch

BODY ELECTRICAL
Lighting, Wiper and Washers, Door Lock, Meter, Audio / Visual, Navigation, Park Assit/Monitoring, Horn, Other systems

BODY
Windshield / Windowglass, Mirror, Instrument Panel, Seat, Engine Hood / Door, Exterior, Interior, Sliding Roof

COMMUNICATION SYSTEM
CAN Communication

NEW CAR FEATURES
New model outline - Exterior appearance, Exterior, Interior, Equipment, Safety, Performance
Engines
Chassis - Clutch, E352, EA64F, E352F / E359F Manual Transaxles; U140F,U241E Automatic Transaxles; Transfer, Drive shaft and Propeller shaft, Rear differential, 4WD system, Suspension & Axle, Tire pressure warning system, Brake, Steering
Body - Body structure, Enhancement of product appeal
Body electrical - Multiplex communication, Lighting, Meter, Wiper and Washer, Air conditioner, Navigation system with AV system, Power window system, Smart entry and Start system, Door lock control system, Engine immobilizer, Theft deterrent, SRS airbag, Seat belt reminder, Cruise control, Power seat, Seat heater, Front wiper deicer, Headlight cleaner, Sliding roof, Audio system

ELECTRICAL WIRING DIAGRAM
Engine - Charging, Engine control, Entry and Start system, Ignition, Radiator fan and Condenser fan, Starting
Transmission - ECT and A/T indicator, Shift lock
Drive line - 4WD
Suspension & Axle - Tire pressure warning system
Brake - ABS, TRS, VSC, Downhill assist, Hill start assist
Steering - EPS
Heater & Air Conditioner System - Automatic air conditioner, Manual air conditioner
Restraints - Seat belt warning, SRS
Securities - Engine immobiliser system, Theft deterrent
Cruise Control System - Cruise control
Body Electrical - Audio system, Automatic light control, Back-up light, Cigarette lighter, Front fog light, Headlight, Interior light, Stop light, Navigation system, Wireless door lock control and much much more
Body - Automatic Glare-Resistant EC mirror, Front window deicer, Mirror heater, Power heater, Power seats, Power windows, Rear window defogger, Remote control mirror, Seat heater, Sliding roof
Communication System - Multiplex communication system

WIRING DIAGRAMS FOR ALL CAR UNITS

BODY REPAIR
Body Panel Replacement, Body Dimensions, Paint, Coating
