New Holland Wheeled Excavator EW160 service manual

Description New Holland Wheeled Excavator EW160 service manual

New Holland Wheeled Excavator EW160 pdf service & repair manual

Technical data, specification, troubleshooting, maintenance, electrical diagrams, hydraulic schematics, disassembly, assembly, removal, installation and other information

MANUAL CONTENT:
Technical Handbook
Servicing and repair

Warnings and symbols
Danger in the event of non-obser-vance of the safety instructions
Organizational measures
Selection and qualification of personnel - basic responsibilities
Safety instructions governing specific operational phases
Standard operation
Special work in conjunction with utilization of the machine maintenance and repairs
Warning of special dangers
Electric energy
Gas, dust, steam and smoke
Hydraulic and pneumatic equipment
Noise
Oil, grease and other chemical substances
Transporting and towing - recommissioning
Repair work - safety instructions
Accumulators, safety instructions
ENGINE
Engine, repair instructions
Assisted starting (with jump-leads) - safety instructions
WELDING OPERATIONS
Welding operations - safety instructions

Service Data

Tools
Foreword
PCS tester
Big leather test case with contents 220V/AC
Solenoid valve tester
Measuring adapter
Vacuum pump
Environment-protection plugs (not shown)
Pressure gauge
Stroke-measuring device
Cylinder tools
Fitting suspension
Protective sleeve
Fining device
Axle and gearbox tools
Axle
Hydraulic pump
Fitting punch
Stud
Fitting device
Thickness gauge
Swing gearbox
VACUUM PUMP
Connecting the vacuum pump

UNDERCARRIAGE
Undercarriage components
Chassis
Steering swing axle
Rigid axle
Cardan shaft
Removal and fitting of cardan shaft

WHEELS AND TYRES
Tyre inflation pressure - Safety instructions
Checking the tyre inflation pressure - Refilling the tyre
Table of tyre inflation pressures
Tyres and wheels - safety instructions
Wheel components
Changing a wheel
Wheels - Tread pattern arrangement

Support
Outrigger stabilizers
Levelling blade
Steps
Right-hand steps / Toolbox components
Left-hand steps

SUPERSTRUCTURE

BALL-BEARING SWING BEARING
General information
Dismantling / installing the ball-bearing swing ring
Tools and aids
Dismantling the swing bearing
Installing the swing bearing
Swing gearbox pinion / Checking the tooth flank clearance on the swing ring

ENGINE, INSTALLATION
Removing and installing the diesel engine
General information
Removing the diesel engine
Installing the diesel engine

ENGINE, COUPLING
General information
Removing the coupling
Installing the coupling

Diesel Engine

Gear Box Axles
Hydraulic System
Foreword
Safety Instructions
Danger in the event of non-observance of the safety instructions
Rules for safely at work
Depressurizing the hydraulic system

Venting the hydraulic system
Reason for venting
Venting
Hydraulic tank
Top servo control caps
Hydraulic pumps and hydraulic motors
Hydraulic cylinder
Brake system
After venting

Flushing the hydraulic system

Description of the hydraulic system
Technical data
Hydraulic circuit diagram P/N 4 530 124.00 superstructure
Hydraulic circuit diagram P/N 4 530 135.00 undercarriage
Survey of components in the hydraulic circuit diagram

Hydraulic components
Drive engine
Twin variable displacement pump
Demand control
Power control
Load limit regulator
Swing pump
Twin gear pump
Twin gear pump
Oil cooler with fan drive
Swing mode valve
Filter
Load limit regulator PCS III
Swing gearbox
Sv/mg motor
Speed sensor
Hydraulic reservoir

ELECTRICAL SYSTEM
Technical handbook
Fundamentals of electrical engineering
Technical handbook
Interpretation of wiring diagrams
Electrical circuit diagram
Electrical components in circuit diagram
