10.2001 / USA market / 1 CD / Windows OS, MacOS, Linux / 32 & 64 bit

New Holland Disc Mower Conditioner 474, 489, 492, 1465 PDF workshop service & repair manual

Schematics, technical data, specifications, troubleshooting, maintenance, disassembly, assembly, removal, installation and other information

Languages: English

MANUAL CONTENT:
GENERAL INFORMATION
Precautionary Statements
Safety
Serial Number
How the Mower-Conditioner Functions
Power Distribution
Tapered Spline Connections - Hammer Seating
Hardware Torque Values
Installation of Adjustable Fittings
Standard Torque Data For Hydraulic Tubes and Fittings
Pipe Thread Fitting Torque
Installation of ORFS (O Ring Flat Faced) Fittings
Lubrication
Sealants
Ecology and the Environment
International Symbols

IMPLEMENT POWER TAKE-OFF (PTO)
PTO Assembly
Joint Replacement
Telescoping Shaft and Tube
Front PTO Assembly
PTO Shaft Shields
Quick-Detachable Yoke
PTO Drive Shaft
Repair Time Schedule

HYDRAULIC SYSTEMS
Hydraulic Cylinders, Optional
Repair Time Schedule

FRAMES
Tongue
Jack
Repair Time Schedule

ELECTRICAL SYSTEM
Light Wiring Harness, Model 1465
Installing the Socket
Repair Time Schedule

ATTACHMENTS / HEADERS
Cutter Bar
Knife Head Bolt
Knife Assembly
Sharpening the Knife Sections
Replacing the Knife Sections
Knife Head
Knife Head Bushing
Guards
Hold-down Clips
Repair Time Schedule

SAFETY DECALS
