Komatsu Bulldozer D65EX-18 D65PX-18 D65WX-18 service & repair manual

Description Komatsu Bulldozer D65EX-18 D65PX-18 D65WX-18 service & repair manual

Komatsu Bulldozer D65EX-18, D65PX-18, D65WX-18 pdf workshop service repair manual + operation & maintenance manual

Serial numbers:
90001 and up
90997 and up
91310 and up
96001 and up

Specifications, maintenance, testing, technical documentation, troubleshooting, electrical wiring diagrams, hydraulic schematics, adjusting, assembly, disassembly, removal, installation instructions and other information

MANUAL CONTENT:
SPECIFICATION
SPECIFICATION DRAWING
SPECIFICATIONS
WEIGHT TABLE
TABLE OF FUEL, COOLANT, AND LUBRICANTS

STRUCTURE AND FUNCTION
UREA SCR SYSTEM
LAYOUT DRAWING OF UREA SCR SYSTEM
UREA SCR SYSTEM DIAGRAM
FUNCTION OF UREA SCR SYSTEM
FUNCTION OF AdBlue/DEF SYSTEM
INDUCEMENT STRATEGY
COMPONENT PARTS OF UREA SCR SYSTEM
AdBlue/DEF MIXING TUBE
SCR ASSEMBLY
AdBlue/DEF TANK
AdBlue/DEF PUMP
AdBlue/DEF INJECTOR
AdBlue/DEF HOSE
AdBlue/DEF TANK HEATING VALVE
BOOT-UP SYSTEM
LAYOUT DRAWING OF BOOT-UP SYSTEM
SYSTEM OPERATING LAMP SYSTEM
SYSTEM OPERATING LAMP SYSTEM DIAGRAM
FUNCTION OF SYSTEM OPERATING LAMP SYSTEM
BATTERY DISCONNECT SWITCH
LAYOUT DRAWING OF BATTERY DISCONNECT SWITCH
FUNCTION OF BATTERY DISCONNECT SWITCH
ENGINE SYSTEM
LAYOUT DRAWING OF ENGINE RELATED PARTS
ENGINE CONTROL SYSTEM
LAYOUT DRAWING OF ENGINE CONTROL
ENGINE CONTROL SYSTEM DIAGRAM
FUNCTION OF ENGINE CONTROL SYSTEM
AUTOMATIC IDLE STOP SYSTEM
AUTOMATIC IDLE STOP SYSTEM DIAGRAM
FUNCTION OF AUTOMATIC IDLE STOP SYSTEM
COMPONENT PARTS OF ENGINE SYSTEM
DAMPER
KVGT
EGR SYSTEM
EGR VALVE
EGR COOLER
KCCV SYSTEM
KCCV VENTILATOR
KDPF
COOLING SYSTEM
LAYOUT DRAWING OF COOLING SYSTEM
SPECIFICATIONS OF COOLING SYSTEM
COMPONENT PARTS OF COOLING SYSTEM
COOLING FAN PUMP
COOLING FAN MOTOR
HYDRAULIC OIL COOLER BYPASS VALVE
CONTROL SYSTEM
LAYOUT DRAWING OF CONTROL SYSTEM PARTS
PALM COMMAND CONTROL SYSTEM
PALM COMMAND CONTROL SYSTEM DIAGRAM
MACHINE MONITOR SYSTEM
MACHINE MONITOR SYSTEM DIAGRAM
FUNCTION OF MACHINE MONITOR SYSTEM
KOMTRAX SYSTEM
KOMTRAX SYSTEM DIAGRAM
OMPONENT PARTS OF CONTROL SYSTEM
MACHINE MONITOR
KOMTRAX TERMINAL
POWER TRAIN CONTROLLER
DECELERATOR PEDAL POTENTIOMETER
ENGINE CONTROLLER
HYDRAULIC SYSTEM
LAYOUT DRAWING OF HYDRAULIC SYSTEM
CLSS
STRUCTURE OF CLSS
FUNCTION OF CLSS
COMPONENT PARTS OF HYDRAULIC SYSTEM
HYDRAULIC TANK
WORK EQUIPMENT AND HSS PUMP
LS VALVE
PC VALVE
PC-EPC VALVE
CONTROL VALVE
POWER TRAIN SYSTEM
LAYOUT DRAWING OF POWER TRAIN SYSTEM
OPERATION OF POWER TRAIN SYSTEM
TRANSMISSION, STEERING, AND BRAKE CONTROL
LAYOUT DRAWING OF TRANSMISSION, STEERING, AND BRAKE CONTROL SYSTEM
FUNCTION OF TRANSMISSION, STEERING, AND BRAKE CONTROL
HSS SYSTEM
HSS SYSTEM DIAGRAM
FUNCTION OF HSS SYSTEM
CENTRALIZED PRESSURE PICKUP PORT
LAYOUT OF CENTRALIZED PRESSURE PICKUP PORT
FUNCTION OF CENTRALIZED PRESSURE PICKUP PORT
COMPONENT PARTS OF POWER TRAIN SYSTEM
UNIVERSAL JOINT
POWER TRAIN MOUNT
TORQUE CONVERTER AND PTO
LOCKUP CLUTCH ECMV
TRANSMISSION
TRANSMISSION CONTROL VALVE
FORWARD AND REVERSE CLUTCH ECMV AND GEAR SPEED CLUTCH ECMV
MAIN RELIEF VALVE AND TORQUE CONVERTER RELIEF VALVE
TRANSMISSION LUBRICATION RELIEF VALVE
BEVEL GEAR SHAFT, HSS, AND BRAKE
BRAKE VALVE
FINAL DRIVE
SCAVENGING PUMP
STEERING LUBRICATION PUMP AND POWER TRAIN PUMP
HSS MOTOR
ELECTRIC LEVER
WORK EQUIPMENT SYSTEM
WORK EQUIPMENT CONTROL
WORK EQUIPMENT CONTROL SYSTEM DIAGRAM
FUNCTION OF WORK EQUIPMENT CONTROL
LAYOUT OF TILT DOZER, POWER TILT PITCH DOZER AND ANGLE DOZER SERIES
LAYOUT OF POWER ANGLE POWER TILT DOZER SERIES
LAYOUT OF FIXED MULTI-SHANK RIPPER
COMPONENT PARTS OF WORK EQUIPMENT SYSTEM
SELF-PRESSURE REDUCING VALVE
WORK EQUIPMENT LOCK SOLENOID VALVE
PILOT CIRCUIT ACCUMULATOR
BLADE PPC VALVE
RIPPER PPC VALVE
QUICK DROP VALVE
PISTON VALVE
UNDERCARRIAGE AND FRAME
MAIN FRAME
STRUCTURE OF MAIN FRAME
SUSPENSION
STRUCTURE OF SUSPENSION
SPECIFICATIONS OF SUSPENSION
FUNCTION OF SUSPENSION
TRACK FRAME AND IDLER CUSHION
STRUCTURE OF TRACK FRAME AND IDLER CUSHION
FUNCTION OF TRACK FRAME AND IDLER CUSHION
WORK EQUIPMENT
STRUCTURE OF FRONT WORK EQUIPMENT (FOR TILT DOZER AND POWER TILT PITCH DOZER SERIES)
STRUCTURE OF FRONT WORK EQUIPMENT (FOR POWER ANGLE POWER TILT DOZER SERIES)
STRUCTURE OF FRONT WORK EQUIPMENT (ANGLE DOZER SERIES)
STRUCTURE OF FIXED MULTI-SHANK RIPPER
CAB AND ITS ATTACHMENTS
ROPS CAB
STRUCTURE OF ROPS CAB
FUNCTION OF ROPS CAB
CAB MOUNT
STRUCTURE OF CAB MOUNT
FUNCTION OF CAB MOUNT

STANDARD VALUE TABLE
STANDARD VALUE TABLE FOR ENGINE
STANDARD VALUE TABLE FOR MACHINE
MACHINE POSTURE AND PROCEDURE FOR MEASURING PERFORMANCE
STANDARD VALUE TABLE FOR ELECTRICAL
STANDARD VALUE TABLE FOR ELECTRICITY

TESTING AND ADJUSTING
RELATED INFORMATION ON TESTING AND ADJUSTING
TOOLS FOR TESTING AND ADJUSTING
SKETCH OF TOOLS FOR TESTING AND ADJUSTING
ENGINE AND COOLING SYSTEM
TEST ENGINE SPEED
METHOD FOR TESTING ENGINE SPEED
TEST BOOST PRESSURE
METHOD FOR TESTING BOOST PRESSURE
TEST EXHAUST GAS TEMPERATURE
METHOD FOR TESTING EXHAUST GAS TEMPERATURE
TEST EXHAUST GAS COLOR
METHOD FOR TESTING EXHAUST GAS COLOR BY HANDY SMOKE CHECKER
METHOD FOR TESTING EXHAUST GAS COLOR BY SMOKE METER
TEST AND ADJUST VALVE CLEARANCE
METHOD FOR TESTING VALVE CLEARANCE
METHOD FOR ADJUSTING VALVE CLEARANCE
TEST COMPRESSION PRESSURE
METHOD FOR TESTING COMPRESSION PRESSURE
TEST BLOWBY PRESSURE
METHOD FOR TESTING BLOWBY PRESSURE
TEST ENGINE OIL PRESSURE
METHOD FOR TESTING ENGINE OIL PRESSURE
TEST EGR VALVE AND KVGT OIL PRESSURE
METHOD FOR TESTING EGR VALVE AND KVGT OIL PRESSURE
TEST FUEL PRESSURE
METHOD FOR TESTING FUEL PRESSURE
TEST FUEL DISCHARGE, RETURN AND LEAKAGE
METHOD FOR TESTING FUEL DISCHARGE, RETURN AND LEAKAGE
BLEED AIR FROM FUEL SYSTEM
METHOD FOR BLEEDING AIR FROM FUEL SYSTEM
TEST FUEL CIRCUIT FOR LEAKAGE
METHOD FOR TESTING FUEL CIRCUIT FOR LEAKAGE
HANDLE CYLINDER CUT-OUT MODE OPERATION
HANDLE NO-INJECTION CRANKING OPERATION
TEST AND ADJUST AIR CONDITIONER COMPRESSOR BELT TENSION
METHOD FOR TESTING AIR CONDITIONER COMPRESSOR BELT TENSION
METHOD FOR ADJUSTING AIR CONDITIONER COMPRESSOR BELT TENSION
WRITE ASH IN SOOT ACCUMULATION CORRECTION TO ENGINE CONTROLLER
METHOD FOR WRITING ASH IN SOOT ACCUMULATION CORRECTION TO ENGINE CONTROLLER
TEST SCR RELATED FUNCTIONS
TEST AdBlue/DEF PUMP RAISED PRESSURE
TEST INJECTION AMOUNT FROM AdBlue/DEF INJECTOR
TEST AdBlue/DEF LINE HEATER RELAY
TEST AdBlue/DEF PUMP HEATER RELAY
TEST AdBlue/DEF TANK HEATER VALVE
TEST DENITRATION EFFICIENCY OF SCR
CLEAN AdBlue/DEF TANK
METHOD FOR CLEANING AdBlue/DEF TANK
CLEAN AdBlue/DEF TANK MOUNTING PORTION
METHOD FOR CLEANING AdBlue/DEF TANK MOUNTING PORTION
ADJUST DECELERATOR PEDAL
METHOD FOR ADJUSTING DECELERATOR PEDAL
POWER TRAIN
TEST POWER TRAIN OIL PRESSURE
ADJUST TRANSMISSION OUTPUT SHAFT SPEED SENSOR
METHOD FOR ADJUSTING TRANSMISSION OUTPUT SHAFT SPEED SENSOR
TEST BRAKE PERFORMANCE SIMPLY
METHOD FOR TESTING BRAKE PERFORMANCE SIMPLY
ADJUST BRAKE PEDAL
METHOD FOR ADJUSTING BRAKE PEDAL
ADJUST PARKING BRAKE LEVER
METHOD FOR ADJUSTING PARKING BRAKE LEVER
MOVE MACHINE BY RELEASING PARKING BRAKE WHEN MACHINE DOES NOT TRAVEL
METHOD FOR MOVING MACHINE WITH HYDRAULIC TYPE PARKING BRAKE RELEASE SYSTEM
METHOD FOR MOVING MACHINE WITH ELECTRIC TYPE PARKING BRAKE RELEASE SYSTEM
UNDERCARRIAGE AND FRAME
ADJUSTING IDLER CLEARANCE
METHOD FOR ADJUSTING IDLER CLEARANCE
TEST AND ADJUST TRACK TENSION
METHOD FOR TESTING TRACK TENSION
METHOD FOR ADJUSTING TRACK TENSION
HYDRAULIC SYSTEM
RELEASE REMAINING PRESSURE FROM HYDRAULIC SYSTEM
METHOD FOR RELEASING REMAINING PRESSURE FROM HYDRAULIC CIRCUIT
TEST AND ADJUST WORK EQUIPMENT AND HSS OIL PRESSURES
METHOD FOR TESTING WORK EQUIPMENT AND HSS OIL PRESSURES
METHOD FOR ADJUSTING WORK EQUIPMENT AND HSS OIL PRESSURES
BLEED AIR FROM HSS PUMP
METHOD FOR BLEEDING AIR FROM HSS PUMP
TEST OIL PRESSURE OF CONTROL CIRCUIT
METHOD FOR TESTING OIL PRESSURE OF CONTROL CIRCUIT
TEST PPC VALVE OUTPUT PRESSURE
METHOD FOR TESTING PPC VALVE OUTPUT PRESSURE
TEST AND ADJUST PLAY OF WORK EQUIPMENT PPC VALVE
METHOD FOR TESTING PLAY OF WORK EQUIPMENT PPC VALVE
METHOD FOR ADJUSTING PLAY OF WORK EQUIPMENT PPC VALVE
CHECK COOLING FAN SPEED
METHOD FOR CHECKING COOLING FAN SPEED
TEST COOLING FAN CIRCUIT OIL PRESSURE
METHOD FOR TESTING COOLING FAN CIRCUIT OIL PRESSURE
BLEED AIR FROM COOLING FAN PUMP
METHOD FOR BLEEDING AIR FROM COOLING FAN PUMP
TEST THE PARTS CAUSING HYDRAULIC DRIFT IN WORK EQUIPMENT
METHOD FOR TESTING THE PARTS CAUSING HYDRAULIC DRIFT OF BLADE LIFT CYLINDER
TEST INTERNAL OIL LEAKAGE OF WORK EQUIPMENT CYLINDER
METHOD FOR TESTING INTERNAL OIL LEAKAGE OF WORK EQUIPMENT CYLINDER
BLEED AIR FROM WORK EQUIPMENT CYLINDERS
METHOD FOR BLEEDING AIR FROM WORK EQUIPMENT CYLINDERS
WORK EQUIPMENT
ADJUST WORK EQUIPMENT LOCK LEVER
METHOD FOR ADJUSTING WORK EQUIPMENT LOCK LEVER
CAB AND ITS ATTACHMENTS
TEST AND ADJUST OPERATOR'S CAB
METHOD FOR TESTING OPERATOR'S CAB

TROUBLESHOOTING
RELATED INFORMATION ON TROUBLESHOOTING
GENERAL TROUBLESHOOTING POINTS
TROUBLESHOOTING POINTS FOR UREA SCR SYSTEM
SEQUENCE OF EVENTS IN TROUBLESHOOTING
CHECKS BEFORE TROUBLESHOOTING
WALK-AROUND CHECK
TESTING IN ACCORDANCE WITH TESTING PROCEDURE
METHOD FOR CHECKING ELECTRIC EQUIPMENT
PREPARATION FOR TROUBLESHOOTING OF ELECTRICAL SYSTEM
PROCEDURE FOR TESTING AND TROUBLESHOOTING
SYMPTOM AND TROUBLESHOOTING NUMBERS
INFORMATION IN TROUBLESHOOTING TABLE
TROUBLESHOOTING METHOD FOR OPEN CIRCUIT IN WIRING HARNESS OF PRESSURE SENSOR
SYSTEM
CONNECTORS LIST AND LAYOUT
CONNECTOR PIN NUMBERS - CONNECTION TABLE
T-BOXES AND T-ADAPTERS LIST
FUSE LOCATION TABLE
PRECAUTIONS FOR KDPF (KCSF, KDOC) CLEANING AND CHANGE
PREPARATION OF SHORT CIRCUIT ELECTRICAL CONNECTOR (FOR FAILURE CODES [CA1883] AND [CA3135])
FAILURE CODES TABLE
TROUBLESHOOTING BY FAILURE CODE (DISPLAY OF CODE)

DISASSEMBLY AND ASSEMBLY
RELATED INFORMATION ON DISASSEMBLY AND ASSEMBLY
COATING MATERIALS LIST
SPECIAL TOOLS LIST
SKETCHES OF SPECIAL TOOLS
ENGINE AND COOLING SYSTEM
REMOVE AND INSTALL SUPPLY PUMP ASSEMBLY
METHOD FOR REMOVING SUPPLY PUMP ASSEMBLY
METHOD FOR INSTALLING SUPPLY PUMP ASSEMBLY
REMOVE AND INSTALL INJECTOR ASSEMBLY
METHOD FOR REMOVING INJECTOR ASSEMBLY
METHOD FOR INSTALLING INJECTOR ASSEMBLY
REMOVE AND INSTALL CYLINDER HEAD ASSEMBLY
METHOD FOR REMOVING CYLINDER HEAD ASSEMBLY
METHOD FOR INSTALLING CYLINDER HEAD ASSEMBLY
REMOVE AND INSTALL EGR VALVE ASSEMBLY
METHOD FOR REMOVING EGR VALVE ASSEMBLY
METHOD FOR INSTALLING EGR VALVE ASSEMBLY
REMOVE AND INSTALL EGR COOLER ASSEMBLY
METHOD FOR REMOVING EGR COOLER ASSEMBLY
METHOD FOR INSTALLING EGR COOLER ASSEMBLY
REMOVE AND INSTALL STARTING MOTOR ASSEMBLY
METHOD FOR REMOVING STARTING MOTOR ASSEMBLY
METHOD FOR INSTALLING STARTING MOTOR ASSEMBLY
REMOVE AND INSTALL ALTERNATOR BELT
METHOD FOR REMOVING ALTERNATOR BELT
METHOD FOR INSTALLING ALTERNATOR BELT
REMOVE AND INSTALL RADIATOR ASSEMBLY
METHOD FOR REMOVING RADIATOR ASSEMBLY
METHOD FOR INSTALLING RADIATOR ASSEMBLY
REMOVE AND INSTALL HYDRAULIC OIL COOLER ASSEMBLY
METHOD FOR REMOVING HYDRAULIC OIL COOLER ASSEMBLY
METHOD FOR INSTALLING HYDRAULIC OIL COOLER ASSEMBLY
REMOVE AND INSTALL AFTERCOOLER ASSEMBLY
METHOD FOR REMOVING AFTERCOOLER ASSEMBLY
METHOD FOR INSTALLING AFTERCOOLER ASSEMBLY
REMOVE AND INSTALL POWER TRAIN OIL COOLER ASSEMBLY
METHOD FOR REMOVING POWER TRAIN OIL COOLER ASSEMBLY
METHOD FOR INSTALLING POWER TRAIN OIL COOLER ASSEMBLY
REMOVE AND INSTALL COOLING FAN DRIVE ASSEMBLY
METHOD FOR REMOVING COOLING FAN DRIVE ASSEMBLY
METHOD FOR INSTALLING COOLING FAN DRIVE ASSEMBLY
REMOVE AND INSTALL COOLING FAN MOTOR ASSEMBLY
METHOD FOR REMOVING COOLING FAN MOTOR ASSEMBLY
METHOD FOR INSTALLING COOLING FAN MOTOR ASSEMBLY
REMOVE AND INSTALL ENGINE ASSEMBLY
METHOD FOR REMOVING ENGINE ASSEMBLY
METHOD FOR INSTALLING ENGINE ASSEMBLY
REMOVE AND INSTALL ENGINE FRONT OIL SEAL
METHOD FOR REMOVING ENGINE FRONT OIL SEAL
METHOD FOR INSTALLING ENGINE FRONT OIL SEAL
REMOVE AND INSTALL ENGINE REAR OIL SEAL
METHOD FOR REMOVING ENGINE REAR OIL SEAL
METHOD FOR INSTALLING ENGINE REAR OIL SEAL
REMOVE AND INSTALL ENGINE HOOD ASSEMBLY
METHOD FOR REMOVING ENGINE HOOD ASSEMBLY
METHOD FOR INSTALLING ENGINE HOOD ASSEMBLY
REMOVE AND INSTALL FUEL TANK ASSEMBLY
METHOD FOR REMOVING HYDRAULIC TANK ASSEMBLY
METHOD FOR INSTALLING FUEL TANK ASSEMBLY
REMOVE AND INSTALL AdBlue/DEF TANK ASSEMBLY
METHOD FOR REMOVING AdBlue/DEF TANK ASSEMBLY
METHOD FOR INSTALLING AdBlue/DEF TANK ASSEMBLY
REMOVE AND INSTALL AdBlue/DEF TANK SENSOR FLANGE ASSEMBLY
METHOD FOR REMOVING AdBlue/DEF TANK SENSOR FLANGE ASSEMBLY
METHOD FOR INSTALLING AdBlue/DEF TANK SENSOR FLANGE ASSEMBLY
REMOVE AND INSTALL AdBlue/DEF TANK SENSOR
METHOD FOR REMOVING AdBlue/DEF TANK SENSOR
METHOD FOR INSTALLING AdBlue/DEF TANK SENSOR
REMOVE AND INSTALL AdBlue/DEF TANK STRAINER
METHOD FOR REMOVING AdBlue/DEF TANK STRAINER
METHOD FOR INSTALLING AdBlue/DEF TANK STRAINER
REMOVE AND INSTALL KDPF ASSEMBLY
METHOD FOR REMOVING KDPF ASSEMBLY
METHOD FOR INSTALLING KDPF ASSEMBLY
DISASSEMBLE AND ASSEMBLE OF KDPF ASSEMBLY
METHOD FOR DISASSEMBLING KDPF ASSEMBLY
METHOD FOR ASSEMBLING KDPF ASSEMBLY
REMOVE AND INSTALL SCR ASSEMBLY
METHOD FOR REMOVING SCR ASSEMBLY
METHOD FOR INSTALLING SCR ASSEMBLY
REMOVE AND INSTALL KDPF, SCR ASSEMBLY
METHOD FOR REMOVING KDPF, SCR ASSEMBLY
METHOD FOR INSTALLING KDPF, SCR ASSEMBLY
REMOVE AND INSTALL KCCV ASSEMBLY
METHOD FOR REMOVING KCCV ASSEMBLY
METHOD FOR INSTALLING KCCV ASSEMBLY
REMOVE AND INSTALL AdBlue/DEF MIXING TUBE
METHOD FOR REMOVING AdBlue/DEF MIXING TUBE
METHOD FOR INSTALLING AdBlue/DEF MIXING TUBE
REMOVE AND INSTALL AdBlue/DEF INJECTOR
METHOD FOR REMOVING AdBlue/DEF INJECTOR
METHOD FOR INSTALLING AdBlue/DEF INJECTOR
REMOVE AND INSTALL AdBlue/DEF PUMP
METHOD FOR REMOVING AdBlue/DEF PUMP
METHOD FOR INSTALLING AdBlue/DEF PUMP
REMOVE AND INSTALL AdBlue/DEF HOSE
METHOD FOR REMOVING AdBlue/DEF HOSE
METHOD FOR INSTALLING AdBlue/DEF HOSE
REMOVE AND INSTALL AIR CLEANER ASSEMBLY
METHOD FOR REMOVING AIR CLEANER ASSEMBLY
METHOD FOR INSTALLING AIR CLEANER ASSEMBLY
REMOVE AND INSTALL AIR CONDITIONER COMPRESSOR ASSEMBLY
METHOD FOR REMOVING AIR CONDITIONER COMPRESSOR ASSEMBLY
METHOD FOR INSTALLING AIR CONDITIONER COMPRESSOR ASSEMBLY
REMOVE AND INSTALL AIR CONDITIONER CONDENSER ASSEMBLY
METHOD FOR REMOVING AIR CONDITIONER CONDENSER ASSEMBLY
METHOD FOR INSTALLING AIR CONDITIONER CONDENSER ASSEMBLY
POWER TRAIN
REMOVE AND INSTALL DAMPER ASSEMBLY
METHOD FOR REMOVING DAMPER ASSEMBLY
METHOD FOR INSTALLING DAMPER ASSEMBLY
REMOVE AND INSTALL POWER TRAIN UNIT ASSEMBLY
METHOD FOR REMOVING POWER TRAIN UNIT ASSEMBLY

MAINTENANCE STANDARD
ENGINE AND COOLING SYSTEM
MAINTENANCE STANDARD OF DAMPER
MAINTENANCE STANDARD OF COOLING SYSTEM
MAINTENANCE STANDARD OF COOLING FAN PUMP
MAINTENANCE STANDARD OF SERVO VALVE
MAINTENANCE STANDARD OF COOLING FAN MOTOR POWER TRAIN
MAINTENANCE STANDARD OF UNIVERSAL JOINT
MAINTENANCE STANDARD OF POWER TRAIN MOUNT
MAINTENANCE STANDARD OF TORQUE CONVERTER AND PTO
MAINTENANCE STANDARD OF LOCKUP CLUTCH ECMV
MAINTENANCE STANDARD OF TRANSMISSION
MAINTENANCE STANDARD OF TRANSMISSION CONTROL VALVE
MAINTENANCE STANDARD OF FORWARD AND REVERSE CLUTCH ECMV AND GEAR SPEED CLUTCH ECMV
MAINTENANCE STANDARD OF MAIN RELIEF VALVE AND TORQUE CONVERTER RELIEF VALVE
MAINTENANCE STANDARD OF TRANSMISSION LUBRICATION RELIEF VALVE
MAINTENANCE STANDARD OF BEVEL GEAR SHAFT, HSS, AND BRAKE
MAINTENANCE STANDARD OF BRAKE VALVE
MAINTENANCE STANDARD OF FINAL DRIVE
MAINTENANCE STANDARD OF SPROCKET FOR CONVENTIONAL TYPE TRACK SHOE
MAINTENANCE STANDARD OF SPROCKET FOR PLUS TYPE TRACK SHOE
MAINTENANCE STANDARD OF SPROCKET TOOTH PROFILE FULL-SCALE DRAWING FOR CONVENTIONAL TYPE TRACK SHOE
MAINTENANCE STANDARD OF SPROCKET TOOTH PROFILE FULL-SCALE DRAWING FOR PLUS TYPE TRACK SHOE
UNDERCARRIAGE AND FRAME
MAINTENANCE STANDARD OF MAIN FRAME
MAINTENANCE STANDARD OF SUSPENSION
MAINTENANCE STANDARD OF TRACK FRAME AND IDLER CUSHION
MAINTENANCE STANDARD OF IDLER
MAINTENANCE STANDARD OF TRACK ROLLER FOR CONVENTIONAL TYPE TRACK SHOES (SINGLE FLANGE TYPE)
MAINTENANCE STANDARD OF TRACK ROLLER FOR CONVENTIONAL TYPE TRACK SHOES (DOUBLE FLANGE TYPE)
MAINTENANCE STANDARD OF TRACK ROLLER FOR PLUS TYPE TRACK SHOES (SINGLE FLANGE TYPE)
MAINTENANCE STANDARD OF TRACK ROLLER FOR PLUS TYPE TRACK SHOES (DOUBLE FLANGE TYPE)
MAINTENANCE STANDARD OF CARRIER ROLLER FOR CONVENTIONAL TYPE TRACK SHOE
MAINTENANCE STANDARD OF CARRIER ROLLER FOR PLUS TYPE TRACK SHOE
MAINTENANCE STANDARD OF CONVENTIONAL TYPE TRACK SHOE
MAINTENANCE STANDARD OF PLUS TYPE TRACK SHOE
MAINTENANCE STANDARD OF SINGLE SHOE
MAINTENANCE STANDARD OF SWAMP SHOE
HYDRAULIC SYSTEM
MAINTENANCE STANDARD OF HYDRAULIC TANK
MAINTENANCE STANDARD OF SCAVENGING PUMP
MAINTENANCE STANDARD OF STEERING LUBRICATION PUMP AND POWER TRAIN PUMP
MAINTENANCE STANDARD OF WORK EQUIPMENT AND HSS PUMP
MAINTENANCE STANDARD OF PC-EPC VALVE
MAINTENANCE STANDARD OF HSS MOTOR
MAINTENANCE STANDARD OF CONTROL VALVE
MAINTENANCE STANDARD OF BLADE PPC VALVE
MAINTENANCE STANDARD OF RIPPER PPC VALVE
MAINTENANCE STANDARD OF ANGLE OPERATION EPC VALVE
MAINTENANCE STANDARD OF QUICK DROP VALVE
MAINTENANCE STANDARD OF WORK EQUIPMENT LOCK SOLENOID VALVE (FOR TILT DOZER AND ANGLE DOZER SERIES)
MAINTENANCE STANDARD OF WORK EQUIPMENT LOCK SOLENOID VALVE (FOR POWER TILT PITCH DOZER SERIES)
MAINTENANCE STANDARD OF WORK EQUIPMENT LOCK SOLENOID VALVE (FOR POWER ANGLEPOWER TILT DOZER SERIES)
WORK EQUIPMENT
MAINTENANCE STANDARD OF FRONT WORK EQUIPMENT (FOR TILT DOZER AND POWER TILT PITCH DOZER SERIES)
MAINTENANCE STANDARD OF FRONT WORK EQUIPMENT (FOR POWER ANGLE POWER TILT DOZER SERIES)
MAINTENANCE STANDARD OF FRONT WORK EQUIPMENT (ANGLE DOZER SERIES)
MAINTENANCE STANDARD OF CUTTING EDGE AND END BIT
MAINTENANCE STANDARD OF BLADE LIFT CYLINDER (FOR TILT DOZER AND POWER TILT PITCH DOZER, AND ANGLE DOZER SERIES)
MAINTENANCE STANDARD OF BLADE LIFT CYLINDER (FOR POWER ANGLE POWER TILT DOZER SERIES)
MAINTENANCE STANDARD OF BLADE TILT CYLINDER (FOR TILT DOZER AND POWER TILT PITCH DOZER, AND ANGLE DOZER SERIES)
MAINTENANCE STANDARD OF BLADE TILT CYLINDER (FOR POWER ANGLE POWER TILT DOZER SERIES)
MAINTENANCE STANDARD OF BLADE PITCH CYLINDER (FOR STRAIGHT TILT POWER PITCH DOZER SERIES)
MAINTENANCE STANDARD OF BLADE ANGLE CYLINDER (FOR POWER ANGLE POWER TILT DOZER SERIES)
MAINTENANCE STANDARD OF FIXED MULTI-SHANK RIPPER
MAINTENANCE STANDARD OF RIPPER LIFT CYLINDER
CAB AND ITS ATTACHMENTS
MAINTENANCE STANDARD OF CAB MOUNT

AIR CONDITIONER SYSTEM
PRECAUTIONS FOR REFRIGERANT
AIR CONDITIONER COMPONENT
SPECIFICATIONS OF AIR CONDITIONER
CONFIGURATION AND FUNCTION OF REFRIGERATION CYCLE
OUTLINE OF REFRIGERATION CYCLE
COMPONENT PARTS OF AIR CONDITIONER SYSTEM
AIR CONDITIONER UNIT
CONFIGURATION DIAGRAM OF AIR CONDITIONER UNIT
FUNCTION OF AIR CONDITIONER UNIT
COMPONENT PARTS OF AIR CONDITIONER UNIT
FUNCTION OF EVAPORATOR AS AIR CONDITIONER UNIT COMPONENT
FUNCTION OF HEATER CORE AS AIR CONDITIONER UNIT COMPONENT
FUNCTION OF EVAPORATOR TEMPERATURE SENSOR AS AIR CONDITIONER UNIT COMPONENT
FUNCTION OF SERVO MOTOR AS AIR CONDITIONER UNIT COMPONENT
STRUCTURE OF EXPANSION VALVE AS AIR CONDITIONER UNIT COMPONENT
FUNCTION OF EXPANSION VALVE AS AIR CONDITIONER UNIT COMPONENT
OPERATE EXPANSION VALVE AS AIR CONDITIONER UNIT COMPONENT
FUNCTION OF DUAL PRESSURE SWITCH
AIR CONDITIONER CONTROLLER
STRUCTURE OF AIR CONDITIONER CONTROLLER
COMPRESSOR
STRUCTURE OF COMPRESSOR
SPECIFICATIONS OF COMPRESSOR
FUNCTION OF COMPRESSOR
CONDENSER
STRUCTURE OF CONDENSER
SPECIFICATIONS OF CONDENSER
FUNCTION OF CONDENSER
RECEIVER DRIER
STRUCTURE OF RECEIVER DRIER
SPECIFICATIONS OF RECEIVER DRIER
FUNCTION OF RECEIVER DRIER
SENSORS FOR AIR CONDITIONER SYSTEM
STRUCTURE OF SUNLIGHT SENSOR
FUNCTION OF SUNLIGHT SENSOR
STRUCTURE OF AMBIENT TEMPERATURE SENSOR
FUNCTION OF AMBIENT TEMPERATURE SENSOR
EXPLANATION OF PROCEDURE FOR TESTING AND TROUBLESHOOTING OF AIR CONDITIONER
CIRCUIT DIAGRAM AND ARRANGEMENT OF CONNECTOR PINS FOR AIR CONDITIONER
AIR CONDITIONER SYSTEM DIAGRAM
INPUT AND OUTPUT SIGNALS OF AIR CONDITIONER CONTROLLER
FUNCTION OF AIR CONDITIONER CONTROLLER
INSTALLATION LOCATIONS OF AIR CONDITIONER PARTS AND ARRANGEMENT OF CONNECTORS
TESTING AIR LEAKAGE (DUCT)
METHOD FOR TESTING AIR LEAKAGE (DUCT)
EXPLANATION FOR TESTING AIR CONDITIONER USING SELF-DIAGNOSIS FUNCTION
HOW TO OPEN THE ELECTRICAL SYSTEM ABNORMALITY RECORD SCREEN IN SERVICE MODE OF
THE MACHINE MONITOR
TEST VENT (MODE) CHANGEOVER
METHOD FOR TESTING VENT (MODE) CHANGEOVER
TESTING FRESH/RECIRC AIR CHANGEOVER
METHOD FOR TESTING FRESH/RECIRC AIR CHANGEOVER
TEST SUNLIGHT SENSOR
METHOD FOR TESTING SUNLIGHT SENSOR
TEST (DUAL) PRESSURE SWITCH FOR REFRIGERANT
METHOD FOR TESTING (DUAL) PRESSURE SWITCH FOR REFRIGERANT
TEST RELAYS
METHOD FOR TESTING RELAYS
AIR CONDITIONER TROUBLESHOOTING CHART
INFORMATION DESCRIBED IN TROUBLESHOOTING TABLE
FAILURE CODE [879AKA] A/C Recirculation Air Temperature Sensor Open Circuit
FAILURE CODE [879AKB] A/C Recirculation Air Temperature Sensor Short Circuit
FAILURE CODE [879BKA] A/C Fresh Air Temperature Sensor Open Circuit
FAILURE CODE [879BKB] A/C Fresh Air Temperature Sensor Short Circuit
FAILURE CODE [879CKA] Ventilating Sensor Open Circuit
FAILURE CODE [879CKB] Ventilating Sensor Short Circuit
FAILURE CODE [879DKZ] Sunlight Sensor Open Circuit or Short Circuit
FAILURE CODE [879EMC] Ventilation Damper Malfunction
FAILURE CODE [879FMC] Air Mix Damper Malfunction
FAILURE CODE [879GKX] Refrigerant Pressure Input Signal Out of Range
A-1 TROUBLESHOOTING FOR POWER SUPPLY SYSTEM (AIR CONDITIONER DOES NOT OPERATE)
A-2 TROUBLESHOOTING OF COMPRESSOR SYSTEM (AIR IS NOT COOLED)
A-3 TROUBLESHOOTING FOR BLOWER MOTOR SYSTEM (NO AIR COMES OUT OR AIR FLOW IS ABNORMAL)
A-4 TROUBLESHOOTING FOR FRESH/RECIRC AIR CHANGEOVER
TROUBLESHOOTING USING GAUGE PRESSURE
CONNECTION OF SERVICE TOOL
METHOD FOR CONNECTING SERVICE TOOL
PRECAUTIONS FOR DISCONNECTING AND CONNECTING HOSES AND TUBES IN AIR CONDITIONER PIPINGS
HANDLE COMPRESSOR OIL

CIRCUIT DIAGRAMS
ELECTRICAL CIRCUIT DIAGRAM
HYDRAULIC CIRCUIT DIAGRAM

Engine SAA6D114E-6 workshop service manual
