JCB Wheel Loading Shovel WLS 432ZX service manual

Description JCB Wheel Loading Shovel WLS 432ZX service manual

JCB Wheel Loading Shovel WLS 432ZX pdf service & repair manual + Cummins engine 6BTAA 5.9 service & operation manual

Serial numbers:
2186000 to 2196000
2079294 to 2081294
1507477 to 1507999

Technical documentation, specifications, maintenance procedures, troubleshooting, electrical wiring diagrams, hydraulic schematics, instructions for adjustment, assembly, disassembly, removal and installation

SERVICE MANUAL CONTENT:
Section 1 - General Information
Introduction
Standard Torque Settings
Service Tools
Service Consumable
Terms and Definitions

Section 2 - Care and Safety
Safety Notices
Important Information
Safety Check List

Section 3 - Routine Maintenance

Section B - Body and Framework
Cab
Centre Pivot
Service Procedures
Air Conditioning
Cooling System
Fault Finding
Rear Chassis

Section C - Electrics
Technical Data
Service Procedures
Harness Data
Circuit Diagrams
Fault Finding

Section E - Hydraulics
Technical Data
Basic System and Operation
Schematic Circuits
Circuit Descriptions
Service Procedures
Pressure Testing
Loader Valve
Pumps
Rams

Section F - Transmission
Towing Procedure
Powershift Transmission
Axles

Section G - Brakes
Technical Data
Service Brake Circuits
Brake Valves and Pedals
Park Brake

Section H - Steering
Technical Data
Hydraulic Steering
Descriptions

Section K - Engine
Technical Data

Engine Cummins 6BTAA 5.9 service & operation manual
