Hitachi Excavator Zaxis ZX450 ZX450LC ZX450H ZX450LCH ZX460LCH ZX480MT ZX480MTH spare parts manual

Description Hitachi Excavator Zaxis ZX450 ZX450LC ZX450H ZX450LCH ZX460LCH ZX480MT ZX480MTH spare parts manual

Hitachi Hydraulic Excavator Zaxis ZX450, ZX450LC, ZX450H, ZX450LCH, ZX460LCH, ZX480MT, ZX480MTH pdf spare parts manual

Serial numbers 010001 ~ up

PARTS MANUAL CONTENT:
UPPERSTRUCTURE
FRAME (1) [RIDE-ON TYPE COUNTERWEIGHT] <450,H,MT,MTH>
FRAME (1) [FIT-IN TYPE COUNTERWEIGHT] <450,H,MT,MTH>
FRAME (1) [FIT-IN TYPE COUNTERWEIGHT] <460>
FRAME (2) <450,H,MT,MTH>
FRAME (2) <460>
COUNTERWEIGHT [RIDE-ON TYPE] <450,H,MT,MTH>
COUNTERWEIGHT SUPPORT [RIDO-ON TYPE] <450,H,MT,MTH>
COUNTERWEIGHT [FIT-IN TYPE] <450,H,MT,MTH>
COUNTERWEIGHT [FIT-IN TYPE] <460>
COUNTERWEIGHT SUPPORT [FIT-IN TYPE]
ENGINE
ENGINE SUPPORT [RIDO-ON TYPE COUNTERWEIGHT] <450,H,MT,MTH>
ENGINE SUPPORT [FIT-IN TYPE COUNTERWEIGHT]
OIL FILTER PIPING
ENGINE OIL DRAIN PIPING
RADIATOR
RADIATOR SUPPORT [RIDE-ON TYPE COUNTERWEIGHT] <450,H,MT,MTH>
RADIATOR SUPPORT [FIT-IN TYPE COUNTERWEIGHT]
RESERVE TANK <450,H,MT,MTH>
RESERVE TANK <460>
AIR CLEANER <450,H,MT,MTH>
AIR CLEANER <460>
PRE CLEANER <450,H,MT,MTH>
PRE CLEANER <460>
MUFFLER
FUEL PIPING <450,H,MT,MTH>
FUEL PIPING <460>
FUEL TANK <450,H,MT,MTH>
FUEL TANK <460>
FUEL DOUBLE FILTER
FUEL FEED PUMP <450,H,MT,MTH>
FUEL FEED PUMP <460>
PUMP DEVICE
SWING DEVICE : RIGHT
SWING DEVICE : LEFT
SWING DEVICE SUPPORT
OIL TANK
SUCTION PIPING
DELIVERY PIPING
RETURN PIPING <450,H,MT,MTH>
RETURN PIPING <460>
DRAIN PIPING
MAIN PIPING (1) <450,H,MT,MTH>
MAIN PIPING (1) <460>
MAIN PIPING (2) <450,H,MT,MTH>
MAIN PIPING (2) <460>
ENGINE CONTROL CABLE
ENGINE CONTROL MOTOR
ENGINE STOP CABLE
CONTROL LEVER (FRONT & SWING)
CONTROL LEVER (TRAVEL) <450,H,MT,MTH>
CONTROL LEVER (TRAVEL) <460>
LOCK LEVER
CONTROL VALVE
PILOT PIPING (1)
PILOT PIPING (2-1)
PILOT PIPING (2-2)
PILOT PIPING (3) <450,H,MT,MTH>
PILOT PIPING (3) <460>
PILOT PIPING (4-1) <450,H,MT,MTH>
PILOT PIPING (4-2) <450,H,MT,MTH>
PILOT PIPING (4-1) <460>
PILOT PIPING (4-2) <460>
CONSOLE
CONSOLE COVER
CONSOLE COVER [EXPORT] <450,H,MT,MTH>
RIGHT COVER
RIGHT COVER [EXPORT] <450,H,MT,MTH>
MONITOR
RADIO (AM/FM)
CONTROL UNIT
ELECTRIC PARTS (1) <450,H,MT,MTH>
ELECTRIC PARTS (1) <460>
ELECTRIC PARTS (2)
ELECTRIC PARTS (3)
ELECTRIC PARTS (4) <450,H,MT,MTH>
ELECTRIC PARTS (4) <460>
ELECTRIC PARTS (5) <450,H,MT,MTH>
ELECTRIC PARTS (5) <460>
ELECTRIC PARTS (6) <450,H,MT,MTH>
ELECTRIC PARTS (6) <460>
ELECTRIC PARTS (7) [DOMESTIC] <450,H,MT,MTH>
ELECTRIC PARTS (7) [EXPORT] <450,H,MT,MTH>
ELECTRIC PARTS (7) [EXPORT] <460>
HEAD LAMP <450>
FOG LAMP (1) <H,MTH>
FOG LAMP (2)
BOOM LIGHT (R) [WITH LIGHT COVER] <460>
OVER LOAD ALARM
MOTION ALARM
AIR-CONDITIONER
AIR-CON. UNIT
AIR-CONDITIONER (2-1) <450,H,MT,MTH
AIR-CONDITIONER (2-2) <460>
COMPRESSOR
CAR HEATER (1)
CAR HEATER (2)
DUCT (AIR-CON.)
DUCT (HEATER)
REAR BOX (AIR-CON.)
REAR BOX (12V POWER SUPPLY)
CAB SUPPORT <450,460,MT>
CAB <450,MT>
CAB (STD) <460>
CAB (WITH GUARD SEAT) <460>
CAB (WITH VANDAL HOOK) <460>
CAB (OPG) <460>
CAB (1) <450,460,MT>
CAB (2) <450,MT>
CAB (2) <460>
CAB (3) <450,460,MT>
CAB (3) [WITH VANDAL HOOK] <460>
CAB (4) <450,460,MT>
CAB (5) <450,MT>
CAB (5) <460>
CAB (6) <450,MT>
CAB (6) <460>
CAB (7) <450,460,MT>
CAB (8) [OPG] <460>
CAB GUARD <450,460,MT>
CAB GUARD (OPG) <460>
WINDOW GUARD <460>
CAB SUPPORT <H,MTH>
CAB PARTS <H,MTH>
CAB <H,MTH>
CAB (1) <H,MTH>
SASH <H,MTH>
REAR WINDOW <H,MTH>
CAB (2) <H,MTH>
CAB (3) <H,MTH>
DOOR CATCH <H,MTH>
CAB (4) <H,MTH>
FRONT GUARD <H,MTH>
SUNSHADE <450,460,MT>
SUNVISOR <H,MTH>
SUNVISOR <460>
EXTINGUISHER <H,MTH>
EXTINGUISHER (CAB OUTSIDE) <450,H,>
REARVIEW MIRROR
WINDOW WASHER
FLOOR PARTS
FLOOR PLATE
SEAT
SUSPENSION SEAT (WITH HEATER) <460>
AIR-SUSPENSION SEAT (WITH HEATER) <460>
HEATER SEAT PARTS <460>
SEAT BELT
SEAT BELT (SUSPENSION SEAT) <460>
SEAT BELT (AIR-SUSPENSION SEAT) <460>
SEAT STAND <DOMESTIC>
SEAT STAND
COVER (1)
COVER (2-1) <450,H,MT,MTH>
COVER (2-2) <450,H,MT,MTH>
COVER (2-3) <450,H,MT,MTH>
COVER (2-1) <460>
COVER (2-2) <460>
COVER (2-3) <460>
COVER (3-1) <450,H,MT,MTH>
COVER (3-2) <450,H,MT,MTH>
COVER (3-3) <450,H,MT,MTH>
COVER (3-1) <460>
COVER (3-2) <460>
COVER (3-3) <460>
COVER (4-1) <450,H,MT,MTH>
COVER (4-2) <450,H,MT,MTH>
COVER (4-1) <460>
COVER (4-2) <460>
COVER (5) [RIDE-ON TYPE COUNTERWEIGHT] <450,H,MT,MTH>
COVER (5) [FIT-IN TYPE COUNTERWEIGHT]
LUBRICATOR BOX <450,H,MT,MTH>
LUBRICATOR BOX <460>
ENGINE COVER <450,H,MT,MTH>
ENGINE COVER <450,H,MT,MTH>
ENGINE COVER <460>
UNDER COVER <450,MT>
UNDER COVER <460>
UNDER COVER <H,MTH>
HANDRAIL
ELECTRIC GREASE GUN

UNDERCARRIAGE
TRACK FRAME (STD. TRACK)
TRACK FRAME (LC TRACK) <450LC,450LCH>
TRACK FRAME (LC TRACK) <460>
TRACK FRAME (MT TRACK)
TRACK SIDE STEP <450>
TRACK SIDE STEP <460>
TRACK SIDE STEP <H>
TRACK SIDE STEP <MT>
TRACK SIDE STEP <MTH>
ADDITIONAL STEP <460>
TRACK GUARD <450>
TRACK GUARD <450LC>
TRACK GUARD <450H>
TRACK GUARD <450LCH,460LCH>
TRACK GURRD <480MT>
TRACK GURRD <480MTH>
FULL-LENGTH TRACK GUARD (STD. TRACK)
FULL-LENGTH TRACK GUARD (LC TRACK)
FULL-LENGTH TRACK GUARD (MT TRACK)
TRACK UNDER COVER <460>
SWING BEARING <450,H,MT,MTH>
SWING BEARING <460>
TRAVEL DEVICE (STD. TRACK. LC TRACK)
TRAVEL DEVICE (MT TRACK)
TRANSMISSION (TRAVEL) (MT TRACK)
FRONT IDLER (L) (STD. TRACK)
FRONT IDLER (R) (STD. TRACK)
FRONT IDLER (LC TRACK)
FRONT IDLER (MT TRACK)
ADJUSTER (STD. TRACK, LC TRACK)
ADJUSTER (MT TRACK)
UPPER ROLLER (STD. TRACK)
UPPER ROLLER (LC TRACK)
UPPER ROLLER (MT TRACK)
LOWER ROLLER (STD. TRACK)
LOWER ROLLER (LC TRACK)
LOWER ROLLER (MT TRACK)
TRACK-LINK 600G (STD. TRACK)
TRACK-LINK 600G (LC TRACK)
TRACK-LINK 600G (MT TRACK)
TRACK-LINK 750G (STD. TRACK)
TRACK-LINK 750G (LC TRACK)
TRACK-LINK 750G (MT TRACK)
TRACK-LINK 900G (LC TRACK)
TRACK-LINK 900G (MT TRACK)
CENTER JOINT
TRAVEL PIPING (STD. TRACK)
TRAVEL PIPING (LC TRACK, MT TRACK)
TRAVEL PIPING COVER (STD. TRACK, LC TRACK)
TRAVEL PIPING COVER (MT TRACK)
LUBRICATE PIPING (SWING BEARING)

BACKHOE ATTACHMENTS
STD. BOOM 7.0M <450.MT>
H BOOM 7.0M <H,MTH,460>
BE BOOM 6.3M
BOOM PARTS
STD. ARM 3.4M
SHORT ARM 2.9M <450,H,MT,MTH>
LONG ARM 4.9M <450,H,MT,MTH>
SEMI-LONG ARM 3.9M
H ARM 3.4M <H,MTH,460>
BE ARM 2.9M
BUCKET 1.15 [JIS 94] <450,H,MT,MTH>
BUCKET 1.4 [JIS 94] <450,H,MT,MTH>
BUCKET 1.6 [JIS 94]
BUCKET 1.9 [JIS 94]
BUCKET 2.1 [JIS 94]
BUCKET 2.3 [JIS 94]
ROCK BUCKET 1.9 [JIS 94]
ROCK BUCKET 1.9 [JIS 94] (SIDEBAR-TYPE)
RIPPER BUCKET 1.3 [JIS 94]
ONE-POINT RIPPER
FRONT PIPING (STD. BOOM, H BOOM)
FRONT PIPING (BE BOOM)
FRONT PIPING (STD. ARM, H ARM)
FRONT PIPING (BE ARM)
FRONT PIPING (SHORT ARM) <450,H,MT,MTH>
FRONT PIPING (LONG ARM) <450,H,MT,MTH>
FRONT PIPING (SEMI-LONG ARM)
AUTO. LUBRICATE SYSTEM <450,H,MT,MTH>
AUTO. LUBRICATE SYSTEM <460>
AUTO. LUBRICATE PIPING (BOOM) : <450,H,MT,MTH>
AUTO. LUBRICATE PIPING (ARM) : <450,H,MT,MTH>
AUTO. LUBRICATE PIPING (BOOM) : DIVIDER VALVE <450,H,MT,MTH>
AUTO. LUBRICATE PIPING (ARM) : DIVIDER VALVE <450,H,MT,MTH>
LUBRICATE PIPING (BOOM)
LUBRICATE PIPING (BE BOOM)
LUBRICATE PIPING (ARM)
LUBRICATE PIPING (BE ARM)
HOSE RUPTURE VALVE PIPING (BOOM)
HOSE RUPTURE VALVE PIPING (ARM)
HOSE RUPTURE VALVE PIPING (BE ARM)

LOADER ATTACHMENTS
LOADER FRONT
LOADER MAIN PIPING
LOADER CONTROL LEVER <450,H,MT,MTH>
LOADER PILOT PIPING
LOADER FRONT PIPING
LOADER LUBRICATE PIPING <450,H,MT,MTH>
LOADER BUCKET 2.3 (BOTTOM DUMP) <450,H,MT,MTH>
LOADER BUCKET 2.6 (BOTTOM DUMP) <450,H,MT,MTH>

BREAKER PARTS
MAIN PIPING (BREAKER) <450,H,MT,MTH>
MAIN PIPING (BREAKER) <460>
FILTER (BREAKER)
CONTROL PEDAL (BREAKER)
CONTROL PEDAL (BREAKER) [ACCELERATOR PEDAL TYPE]
PILOT PIPING
BREAKER PARTS
ELECTRIC PARTS (BREAKER)
BOOM PARTS (BREAKER)
ARM PARTS (BREAKER)
FRONT PIPING: 1 (OKADA/FURUKAWA BREAKER) [STD. BOOM, H BOOM] <450,H,MT,MTH>
FRONT PIPING: 2 (OKADA/FURUKAWA BREAKER) [STD. BOOM, H BOOM] <450,H,MT,MTH>
FRONT PIPING: 1 (NPK BREAKER) <450,H,MT,MTH>
FRONT PIPING: 2 (NPK BREAKER) <450,H,MT,MTH>
BOOM PIPING (STD. BOOM, H BOOM) [BREAKER & CRUSHER]
BOOM PIPING (BE BOOM) [BREAKER & CRUSHER]
ARM PIPING (STD. ARM, H ARM) [BREAKER & CRUSHER]
ARM PIPING (BE ARM) [BREAKER & CRUSHER]
COMMON PIPING (BREAKER & CRUSHER)
PILOT PIPING (BREAKER & CRUSHER)
NAME-PLATE (BREAKER) <450,H,MT,MTH>

ASSIST PIPING
ELECTRIC TYPE CONTROL PARTS <460>
QUICKHITCH PIPING (STD. BOOM, H BOOM) <460>
QUICKHITCH PIPING (BE BOOM) <460>
QUICKHITCH PIPING (STD. ARM, H ARM) <460>
QUICKHITCH PIPING (BE ARM) <460>
QUICKHITCH PIPING (SEMI-LONG ARM) <460>
ASSIST PIPING (STD. BOOM, H BOOM)
ASSIST PIPING (BE BOOM)
ASSIST PIPING (STD. ARM, H ARM)
ASSIST PIPING (BE ARM)
ASSIST PIPING (SEMI-LONG ARM)
QUICKHITCH / ASSIST COMMON PARTS (STD. BOOM, H BOOM)
QUICKHITCH / ASSIST COMMON PARTS (BE BOOM)
CLAMSHELL PIPING (STD. ARM, H ARM)
CLAMSHELL PIPING (BE ARM)
CLAMSHELL PIPING (SEMI-LONG ARM)

COUNTERWEIGHT REMOVAL DEVICE
COUNTERWEIGHT (REMOVAL DEVICE) <450,H,MT,MTH>
C/W LIFTING DEVICE <450,H,MT,MTH>
CYLINDER (REMOVAL DEVICE) <450,H,MT,MTH>
CONTROL SYSTEM (REMOVAL DEVICE) <450,H,MT,MTH>
PILOT PIPING (REMOVAL DEVICE) <450,H,MT,MTH>
HIGH-PRESSURE PIPING (REMOVAL DEVICE) <450,H,MT,MTH>

TOOLS

NAME-PLATE
